The Geocell Honeycomb Confinement System is a three-dimensional honeycomb structure made of a polymer material such as HDPE, which is unfolded at the construction site and then filled with materials such as soil, gravel or sand to form a monolithic reinforcing system used to enhance foundation capacity, prevent lateral slip and control erosion.
PENNCELL is a kind of prefabricated, expanded, three-dimensional reinforcement cellular confinement system to improve the base condition. Widely used for projects of road foundation, slope protection, river bank protection, and retaining walls. Mainly used along with geotextiles. Lightweight and foldable, easy to transport.
1. It is light, wear-resistant, chemically stable, resistant to light and oxygen aging, acid and alkali, and suitable for different soils and deserts.
2. It has high lateral restrictions and anti-slip, anti-deformation, and effectively enhances the bearing capacity of the roadbed and disperses the load.
3. Changing the geometric dimensions such as the height and welding distance of the geocell can meet different engineering needs.
4. It is flexible and has a small transportation volume; it is easy to connect and has a fast construction speed.
1. The material is folded at the factory for easy transportation.
2. Unfolded on site to form honeycomb cells.
3. The cell is filled with soil, gravel or mixture.
4. Through the “constraint effect” of the honeycomb structure, the material displacement is limited and the overall stability is improved.
| Feature | Geogrid | Geocell (Geocell Honeycomb System) |
|---|---|---|
| Form | Two-dimensional grid or mesh | Three-dimensional expandable honeycomb structure |
| Material | Typically made from PP, PET, or HDPE | Made from HDPE strips welded to form cellular grids |
| Appearance | Flat, open mesh with square or rectangular apertures | Folded sheets that expand into honeycomb shapes |
PENNCELL SM - HDPE Smooth surface cell
PENNCELL TH - HDPE Textured with holes cell
| Type | Thickness | Cell Height | Cell Size (Appx.) |
| PENNCELL SM/TH/ 330 | 1.5mm | 50mm, 75mm, 100mm,150mm, 200mm, 300mm | 248mm x 214mm |
| PENNCELL SM/TH 356 | 1.5mm | 50mm, 75mm, 100mm,150mm, 200mm, 300mm | 267mm x 230mm |
| PENNCELL SM/TH 445 | 1.5mm | 50mm, 75mm, 100mm,150mm, 200mm, 300mm | 320mm x 288mm |
| PENNCELL SM/TH 660 | 1.5mm | 50mm, 75mm, 100mm,150mm, 200mm, 300mm | 489mm x 422mm |
| PENNCELL SM/TH 712 | 1.5mm | 50mm, 75mm, 100mm,150mm, 200mm, 300mm | 527mm x 454mm |
PENNCELL is commonly used in the following projects.
1. River bed protection.
2. Road construction.
3. Gravel foundation.
4. Slope protection.
5. Parking lot.
6. Retaining wall.
